Our Yamaha EF2000iS Extended Run Time Fuel Kit is the safest way to extend the run time of your generator.
Why the Pinellas Power Products Extended Run Fuel System is better and safer than a through the cap system
Product Demonstration Video Installation Instruction Video Fine Tuning and Troubleshooting
All installation instructions for all Pinellas Power Products kits are in an easy to follow step by step video, on a (USB flash-drive) included in each kit. Please take a moment to watch the product videos above to see all the features this product has to offer.
Our Yamaha EF2000iS Extended Run Time Fuel Kit was specifically developed to work correctly with the Yamaha EF2000iS. It is not a through the cap, one size fits all, or a gravity feed system. Our kits use an internal fuel pump included in the kit to transfer fuel so the remote tank does not need to be higher than the generator to work correctly. Simply place the remote tank on the ground next to the generator then connect the fuel hose and you are all set. Please note that this application is a transfer pump, not a lift pump. Due to the small engine size in the EF2000iS the pulse wave is not strong enough to lift fuel more than a couple inches vertically. The fuel tank and the generator must be level with each other. In order to run with loads above 750 watts the Economy mode switch must be in the off position. It is very important that you use only the components supplied in the kit, do not mix and match with locally improvised items due to the fact that they may not be 100% compatible and therefore inhibit performance of the kit. We do our best to select the highest quality components for our kits, for example we tested several different brands of prime ball hose before we chose the Yamaha hose due to the fact that it outlast the other brands and it stays more flexible in cold temperatures.
You will never have to shut down your generator to refuel again. Our Yamaha EF2000iS Extended Run Time Fuel Kit is designed to alternate from one tank to the next while the generator is still running. Our kit will allow you to alternate between as many tanks of any size you choose. Based on manufacturer fuel consumption claims with a 6 gallon fuel tank you can run a Yamaha EF2000iS up to 19 hours at full load or 39 hours at ½ load before alternating to the next fuel tank.
You will never have to risk personal injury again pouring gasoline into a hot generator. With our REMOTE AUXILIARY FUEL TANK SYSTEM you can just switch to a remote fuel supply more safely at a distance of up to 10 feet away from this generator.
This product has been validated for use on gasoline versions of this generator only. It is not recommended for use on propane or dual fuel versions of this generator.
The fuel tank itself is not included in this kit due to the fact that it seems no two customers need the exact same size fuel tank. Here is a link that may help you find the proper sized fuel tank for your needs.
How to use A Fuel Caddy for a Remote Tank Moeller fuel tanks »
Please click on the Product Details tab just below the photos for full technical details.
Please take a look at our other products for the Yamaha EF2000iS.
Gary Burt (verified owner) –
Very pleased with the kits for the Yamaha EF2000is generators. At times I run two of these generators in parallel for my power needs in my RV. I had tried a less expensive gravity feed system and was not happy with the results. Too much hassle monitoring the system to keep both generators running. Then I ran across this system in searching for something better. What a difference. Once installed it is plug and play. I appreciate the engineering and thought put into developing these extended run kits. It is not difficult to install these following the included video instructions if you are somewhat mechanically inclined. Would definitely recommend this system for anyone who wants extended run capability.
